SINOTIMER MC701 Universal Input Short Case PID Intelligent Temperature Controller Meter Heating Cooling Relay SSR Solid State Output, MC701

Rs. 2,236.00
Quantity
Option:

📦 Description


1. Measuring range: 0-1300 degrees Celsius
2. Measurement accuracy: 0.5%FS
3. Display mode: LED
4. Input: universal input, K/E/J/N/S/T/R/B/Pt100 and other signals, can be changed by yourself
5. Resolution: 0.1
6. Temperature display: degrees Fahrenheit / degrees Celsius
7. Power input: AC 100-240V 50/60Hz
8. Operating environment: 0-50 degrees Celsius, 35%-85% RH
9. Opening size: about 6.8 x 6.8cm
10. Overall size: about 7.2 x 7.2 x 8.5cm

Features:
1. Universal input, can change the input signal at will
2. Fahrenheit or Celsius temperature can be switched as required
3. 1 set of control outputs (relay/SSR integrated), free to use relay outputs or SSR outputs
4. Thermometer signal input, with decimal point digital display
5. Using anti-interference chip, liquid crystal display, simple and clear


Specification:
Package Weight
One Package Weight 0.22kgs / 0.49lb
One Package Size 8cm * 8cm * 10cm / 3.15inch * 3.15inch * 3.94inch
Qty per Carton 70
Carton Weight 16.50kgs / 36.38lb
Carton Size 50cm * 34cm * 32cm / 19.69inch * 13.39inch * 12.6inch
Loading Container 20GP: 490 cartons * 70 pcs = 34300 pcs
40HQ: 1137 cartons * 70 pcs = 79590 pcs
