Waveshare MQ-2 Gas Sensor, MQ-2

Rs. 775.00
Quantity
Option:

πŸ“¦ Description

Overview
1. Sensitive for LPG, propane, hydrogen
2. Output voltage boosts along with the concentration of the measured gases increases
3. Fast response and recovery
4. Features boost circuit
5. Adjustable sensitivity
6. Signal output indicator

Specifications
1. Power: 2.5V ~ 5.0V
2. Dimension: 40.0mm * 21.0mm
3. Mounting holes size: 2.0mm

Applications
Gas leakage detector

How to Use
In the case of working with a MCU:
1. VCC: 2.5V ~ 5.0V
2. GND: Power supply ground
3. AOUT: MCU.IO (analog output)
4. DOUT: MCU.IO (digital output)

Package Contents
1. MQ-2 Gas Sensor x1
2. 4-pin custom connector jumper wire x1
Specification:
Package Weight
One Package Weight 0.02kgs / 0.04lb
One Package Size 5cm * 4cm * 1cm / 1.97inch * 1.57inch * 0.39inch
